Top Clamp Tensioned Panel Kit
Top Clamp Tensioned Panel Kit Top Clamp Tensioned Panel Kit Top Clamp Tensioned Panel Kit Top Clamp Tensioned Panel Kit Top Clamp Tensioned Panel Kit Top Clamp Tensioned Panel Kit

Top Clamp Tensioned Panel Kit

In stock

SKU
U5145
These are three pre-configured kits that include everything that is needed to mount a panel, glass or otherwise, from a pair of Fixed Piers to create a partition or two-sided display.
See full product description »
Starting at $92.40
  • Finish : Anodized Machined Aluminum
  • Installation Surface : Ceiling, Floor
  • Weight Capacity : 150 lbs / 68 Kg (per pier)
  • Cable Presentation : Tensioned
  1. 1 Pair (2) of Fixed Pier Sets, 10 ft - Silver Satin
  2. 2 Null-End Stainless Steel Cable, 72-in
  3. 4 Top Clamp

$92.40

Summary
    To realize this inspiration you need:

    fixed pier set 10 ft.

    Top Cable Length

    Choose Top Clamp size

    $92.40

    Summary

      These are three pre-configured kits that include everything that is needed to mount a panel, glass or otherwise, from a pair of Fixed Piers to create a partition or two-sided display. Think of these assortments as Fixed Piers to which a panel may be attached by means of Top Clamps. You may select from three assortments, one each for the small, medium and large Top Clamps. Supplied cables are sufficient to span a distance equal to the height of your display panel plus 16 ft. Cables are to be trimmed to length in the field.

      Each assortment includes the following:

      Pair Fixed Pier, Point-to-Point Set:
         Fixed Pier, Long (2x)
         Fixed Pier, Short (2x)
         10' Barrel-End Stainless Steel Cable
         Cable stop, Spring and Allen Key
         (2x) #6 x 1¼ in. screws and TripleGrip™ anchors
         (2x) #6 x 2 in. wood screw
      Top-Clamp (choose from Small, Medium, Large) (4x)
      Null/Null Cable , 6ft. (2x)

      Rated strength :  150 lbs. when installed by fastening into structural wood with the appropriate fastener and the fastener is engaged 1” or more into lumber. However, the weight capacity of an individual pier/steel cable may be as low as 10 lbs., or less (static load), depending on the mounting hardware and installation technique. Actual capacity is dependent upon the installation. It is the responsibility of the installer to select the correct faster for a particular installation.

      Contact our Customer Service Departement for your personalized solution at 866 935 6949. You may send your drawings by email to info@ASHanging.com.

      Step 3

      Go to
      Step 3

      Step 2

      Go to
      Step 2

      Step 1

      This product
      is part of
      Step 1

      • SKU U5145
      • Material 1.8mm Stainless Steel Cable, solid aluminum parts, nickel plating over brass parts
      • Finish Anodized Machined Aluminum
      • Installation Surface Ceiling, Floor
      • Weight Capacity 150 lbs / 68 Kg (per pier)
      • Cable Presentation Tensioned
      • Installation Skill Do-It-Yourself
      • Product Marking =AS=
      • Product Patented Patent Pending
      • Legacy Systems Families Not Applicable
