Top Clamp Suspended Panel Kit
Top Clamp Suspended Panel Kit Top Clamp Suspended Panel Kit Top Clamp Suspended Panel Kit Top Clamp Suspended Panel Kit Top Clamp Suspended Panel Kit Top Clamp Suspended Panel Kit

Top Clamp Suspended Panel Kit

In stock

SKU
U5140
These are three pre-configured kits that include everything that is needed to suspend a panel, glass or otherwise, from a pair of Fixed Piers to create a two-sided display.
See full product description »
Starting at $40.90
  • Finish : Anodized Machined Aluminum
  • Installation Surface : Ceiling, Floor
  • Weight Capacity : 150 lbs / 68 Kg (per pier)
  • Cable Presentation : Suspended
  1. 2 Barrel-End Stainless Steel Cable, 96-in (C2005LK)
  2. 2 Top Clamp
  3. 2 Fixed Pier Short, Silver Satin

$40.90

Summary
    To realize this inspiration you need:

    BARREL-END CABLE LENGHT

    CHOOSE TOP CLAMP SIZE

    FIXED PIER SHORT

    $40.90

    Summary

      Product Details

      These are three pre-configured kits that include everything that is needed to suspend a panel, glass or otherwise, from a pair of Fixed Piers to create a two-sided display. Think of these assortments as upper mounting points to which a panel may be attached by means of Top Clamps. You may select from three assortments, one each for the small, medium and large Top Clamps. Supplied cables are of sufficient length to suspend the top of a panel up to 8 ft. below the upper attachment. Cables are to be trimmed to length in the field.

      Each assortment includes the following:

      Short Fixed Pier (2x)
      Barrel-End Cable, 8 ft. (2x)
      Top-Clamp (choose from Small, Medium, Large) (2x)

      Rated strength :  150 lbs. when installed by fastening into structural wood with the appropriate fastener and the fastener is engaged 1” or more into lumber. However, the weight capacity of an individual pier/steel cable may be as low as 10 lbs., or less (static load), depending on the mounting hardware and installation technique. Actual capacity is dependent upon the installation. It is the responsibility of the installer to select the correct faster for a particular installation.

      For more details about any of the specific included products, follow the links above.

      Contact our Customer Service Departement for your personalized solution at 866 935 6949. You may send your drawings by email to info@ASHanging.com.

      Step 3

      Go to
      Step 3

      Step 2

      Go to
      Step 2

      Step 1

      This product
      is part of
      Step 1

      Technical Specifications

      • SKU U5140
      • Material 1.8mm Stainless Steel Cable, solid aluminum parts, nickel plating over brass parts
      • Finish Anodized Machined Aluminum
      • Installation Surface Ceiling, Floor
      • Weight Capacity 150 lbs / 68 Kg (per pier)
      • Cable Presentation Suspended
      • Installation Skill Do-It-Yourself
      • Product Marking =AS=
      • Product Patented Patent Pending
      • Legacy Systems Families Not Applicable
