Pro Side Clamp
Pro Side Clamp Pro Side Clamp Pro Side Clamp Pro Side Clamp Pro Side Clamp Pro Side Clamp, Single‐Sided, Small Pro Side Clamp Pro Side Clamp Pro Side Clamp Pro Side Clamp

Pro Side Clamp

In stock
SKU
H3050x
Pro Side Clamps are used for suspending rigid panels and display surfaces in a vertical orientation from any of our cables/cords.
See full product description »
$4.80
  • Finish : Anodized Machined Aluminum
  • Includes : Clamp, Allen key, Nylon Tipped set screw (for panels), Cone Tipped set screw (for panels), Flat Tipped set screw (for cable)
  • Capabilities : Earthquake Mitigation, Anti-Theft
  • Panel/Object Type : Acrylic Pockets, Crushable Panels (Fluted PVC - Foamcore - etc.), Rigid Panels (Sintra - Metal Sheet - Wood - etc.)
  • Weight Capacity : 20 lbs (9 Kg) per attachment
  • Hook Activation : Manually Activated

Product Details

Pro Side Clamps are used for suspending rigid panels and display surfaces in a vertical orientation from any of our cables/cords, but primarily from stainless steel cables. The product family consists of both single-sided and double-sided clamps. Many, if not most, installations require both types.

Pro Side Clamps are made from finely machined aluminum with a very fine brushed surface. Decor jewelry. Then these are finished in a clear anodized surface to maintain these attributes for years.

These are the best side clamps available, anywhere.

The cable-slot bottom is rounded to protect against deforming the cable shape under pressure from the screw. The cable screw is also finished with a flat tip to again avoid damaging stainless steel strands.

These clamps allow you choices for panel attachment methods. Choose the nylon tipped screws against rigid, or even brittle, substrate. The nylon tipped screws will guard against damaging many surfaces. Or, you may choose the cone tipped screws to dig into your panel material for a strong and secure grip. Finally, again using the cone tipped set screws, and display panels with through holes, the screws will pass through the panels and securely land in a cavity for positive display mounting.

A pair of both nylon tipped and cone tipped set screws are supplied for mounting display panels. All set screws are made of stainless steel.

We offer Pro Side Clamps in small, medium and large. The small size and is compatible with panels 1/32" to 0.157" thick. The medium size is compatible with panels 1/32" to 1/4" thick. The large size is compatible with panels 1/32" to 3/8" thick.

This is the connection between a steel cable to clamp. With all the variables in display panel substrate we cannot anticipate the potential strength of the clamp/panel connection.

Step 3

This product
is part of
Step 3

Step 2

Return to
Step 2

Step 1

Return to
Step 1

Technical Specifications

  • SKU H3050x
  • Material Body: 6061 Aluminum | Set Screws: Stainless Steel
  • Finish Anodized Machined Aluminum
  • Includes Clamp, Allen key, Nylon Tipped set screw (for panels), Cone Tipped set screw (for panels), Flat Tipped set screw (for cable)
  • Capabilities Earthquake Mitigation, Anti-Theft
  • Compatible with Cables/Cords
  • Panel/Object Type Acrylic Pockets, Crushable Panels (Fluted PVC - Foamcore - etc.), Rigid Panels (Sintra - Metal Sheet - Wood - etc.)
  • Cable Location Cables Pass beside Panels, Double-sided Display
  • Weight Capacity 20 lbs (9 Kg) per attachment
  • Hook Activation Manually Activated
  • Legacy Systems Families Cable System
Specifications
Panel Thickness Compatibility
  SMALL MEDIUM LARGE
With Nylon Tip Set Screw Min:. 1/16 in
Max:. 0.157 in
Min:. 0.13 in
Max:. 0.27 in
Min:. 0.27 in
Max:. 0.39 in
With Cone Tip Set Screw Min:. 1/32 in
Max:. 0.157 in
Min:. 0.03 in
Max:. 0.27 in
Min:. 0.03 in
Max:. 0.39 in
