Xpo Rail Track - Covid-19 Protection Kit - Hanging System for Plexiglass / Glass
Art & Picture Hanging Systems
Professional, quick and easy install solution for all retail, hairdressers, restaurants, etc. This picture hanging kit hang plexiglass or glass panels from any type of solid ceiling with fixed piers.
- 1 Xpo Rail Track
- 2 Xpo Rail End Cap, Single
- 2 T-End Stainless Steel Cable
- 2 Top Clamp
Our Xpo Rail Track Covid-19 Protection Kit Hanging System for Plexiglass and Glass includes a Xpo Rail Track with T-End Stainless Steel Cables and Top Clamps. This Picture rail hanging kit hangs plexiglass, acrylic sheets or glass panels from any type of solid ceiling.
The Xpo Rail Trasck is a discreet signage track that supports up to 120 lbs.
Retail solution to help you control the spread of Covid-19. Create a safer environment for your employees and customers. These panels will help everyone to keep a safe distance during the current Covid-19 situation.
AS Hanging Display Systems has put together a professional, quick and easy install solution for all environments where clients and staff interact, including retail stores, hairdressers, restaurants, gyms, grocery stores, clinics, and much more.
Cable Trim Kit
Because of the nature of the materials used and to reduce risk of damages on delivery, we have chosen to let our clients provide their own protective panels. We have a complete line of products compatible with ANY of these, whether it be acrylic panels, Plexiglass, Tempered Glass, right up to Sintra boards and foam core substrates!
It is more cost effective to obtain your own material, size and thickness you want directly. Hardware stores offer these, so you can choose directly from their inventory, according to your specific installation while you are there.
Call us at 866-935-6949 for details! We will be happy to help you!
Our Top Clamps are compatible with acrylic panel / plexiglass up to 1/2 in. thick, for Glass Panel follow these guidelines.
Options depend on your type of ceiling and the weight (size) of plexiglass sheet you want to use, The Xpo Rail Trasck is a discreet signage track that supports up to 120 lbs.
It's recommended to order a Cable Trim Kit to ease installation.
Plexiglass / Acrylic Thickness vs Weight (4 x 6 ft. sheet)
|1/4 in.||45 lb||Top Clamp, Small or Medium|
|3/8 in.||65 lb||Top Clamp, Large|
|1/2 in.||85 lb||Top Clamp, Large|
Top Clamp through-hole diameter
|Product||Hole Diameter (without bushing)|
|Top Clamp Small||3/16 in.|
|Top Clamp Medium||3/16 in.|
|Top Clamp Large||1/4 in.|
