Classic Wall Track
Classic Wall Track Classic Wall Track Classic Wall Track Classic Wall Track Classic Wall Track Classic Wall Track Classic Gallery System Classic Wall Track Classic Wall Track Classic Wall Track Classic Wall Track Classic Wall Track

Classic Wall Track

In stock
SKU
A1004

This is the most versatile of our tracks, and the strongest. It will support cables and rods, in suspended or tensioned configurations.

See full product description »
$22.95
  • Finish : Anodized silver, champagne, black | Painted warm white (satin)
  • Includes : 9X #6 x 1.25" colored screws, TripleGrip™ anchors
  • Weight Capacity : 300 lbs (135 Kg) per track
  • Track Length : 72 in (6 ft) / 180 cm
  • Capabilities : Earthquake Mitigation, Anti-Theft, Secure
  • Installation Surface : Linear Wall
  • Fastening : Exposed Fasteners
  • Compatible with : Cables, Rods
  • Cable/Rod Presentation : Suspended, Tensioned

Product Details

This is the most versatile of our tracks, and the strongest too. It will support cables and rods. The open-faced design allows for either to be suspended from the lower lip of the track. This design is very convenient. However, because the track profile also offers a "roof" it appears more finished than common utilitarian J-rails. The roof also plays a part in the Anti-Theft solution. See Anti-Theft Rods.

The open-faced design does make it possible to see the mounting screws but this is mitigated by the fact that the track is commonly mounted above the line of sight. Additionally, the mounting screws, included with each track length, are painted to match the track color.

Installation hardware (screws and anchors) are included with each track. Do NOT double order or be fooled by competitive low-ball offers, which do not include mounting hardware.

Hole pattern: 9 pre-drilled 0.16"/4mm holes for #6 screws. First hole is 4 inches from edge, the remaining are spaced 8 inches on center.

TripleGrip™ anchors may be used to mount the track to brick, cement, gypsum, plaster and ceramic surfaces.

Step 3

Go to
Step 3

Step 2

Go to
Step 2

Step 1

This product
is part of
Step 1

Technical Specifications

  • SKU A1004
  • Material Extruded aluminum track
  • Finish Anodized silver, champagne, black | Painted warm white (satin)
  • Includes 9X #6 x 1.25" colored screws, TripleGrip™ anchors
  • Weight Capacity 300 lbs (135 Kg) per track
  • Track Length 72 in (6 ft) / 180 cm
  • Capabilities Earthquake Mitigation, Anti-Theft, Secure
  • Installation Surface Linear Wall
  • Mounting Style Surface
  • Fastening Exposed Fasteners
  • Installation Skill Do-It-Yourself
  • Compatible with Cables, Rods
  • Cable/Rod Presentation Suspended, Tensioned
  • Vertical Element Compatibility J-End Cable, J-End Cord, J-End Colored Cord, P-End Cable, P-End Cord, C-End Cable, C-End Cord, J-End Cable Tensioner, P-End Cable Tensioner, Tensioning Spring, J-End Rod, P-End Rod, P-End Heavy-Duty Rod, Anti-Theft Secure Rod, Anti-Theft Secure Rod Kit, Custom Shaped Rod, Rod-End Hanger
  • Accessory Compatibility Wall Track End-Cap, Cable Tensioner, Rod-End Hanger
  • Legacy Systems Families Classic Gallery System, Cable System
